Heat Resistant Copper Nickel Wire Curpothal 15 / Alloy 90 For Electric Blankets

Heat Resistant Copper Nickel Wire Curpothal 15 / Alloy 90 For Electric Blankets
Heat Resistant Copper Nickel Wire Curpothal 15 / Alloy 90 For Electric Blankets

Large Image :  Heat Resistant Copper Nickel Wire Curpothal 15 / Alloy 90 For Electric Blankets Get Best Price

Product Details:
Place of Origin: China
Brand Name: Ohmalloy
Certification: ISO SGS CE
Model Number: Ohmalloy015 CuNi10 (Alloy90)
Payment & Shipping Terms:
Minimum Order Quantity: 25kgs
Packaging Details: spool+plywood case
Delivery Time: 10 workdays
Payment Terms: L/C, T/T, , MoneyGram
Supply Ability: 80000kg/week
Detailed Product Description
Density (g/cm3): 8.9 Electrical Resistivity At 20℃ (Ωmm2/m): 0.15
Temperature Factor Of Resistivity(20℃~600℃)X10-5/℃: <50 Conductivity Coefficient At 20℃ (WmK): 59
EMF Vs Cu(μV/℃ )(0~100℃ ): -25 Melting Point (℃): 1100
High Light:

copper alloys

,

copper nickel alloy

Heat Resistant Copper Nickel Wire Curpothal 15 / Alloy 90 For Electric Blankets



OhmAlloy15(Resistance heating wire and resistance wire)
(Common Name:CuNi10,Curpothal 15,NC15)



OhmAlloy15 is a copper-nickel alloy (Cu90Ni10 alloy) with low resistivity for use at temperatures up to 250°C.



Curpothal 15 is typically used for applications such as heating cables, fuses, shunts, resistors and various types of controllers.





Normal composition%

Nickel 10 Manganese -
Copper Bal.



Typical Mechanical properties(1.0mm)

Yield strength Tensile Strength Elongation
Mpa Mpa %
130 290 25



Typical Physical properties

Density (g/cm3) 8.9
Electrical resistivity at 20℃ (Ωmm2/m) 0.15
Temperature factor of resistivity(20℃~600℃)X10-5/℃ <50
Conductivity coefficient at 20℃ (WmK) 59
EMF vs Cu(μV/℃ )(0~100℃ ) -25
Coefficient of thermal expansion
Temperature Thermal Expansion x10-6/K
20 ℃- 400℃ 17.5



Specific heat capacity
Temperature 20℃
J/gK 0.380



Melting point (℃) 1100
Max continuous operating temperature in air (℃) 250
Magnetic properties non-magnetic



Corrosion resistance performance





Alloys



Working In atmosphere at 20℃

Working at max temperature 200℃

Air and oxygen contain

gases

gases with Nitrogen

gases with sulfur

oxidability

gases with sulfur

reductibility

carburization
OhmAlloy015 good general general general bad good



Style of supply

Alloys Name Type Dimension
OhmAlloy015W Wire D=0.06mm~8mm
OhmAlloy015R Ribbon W=0.4~40 T=0.05~2.9mm
OhmAlloy015S Strip W=8~200mm T=0.1~3.0
OhmAlloy015F Foil W=6~120mm T=0.005~0.1
OhmAlloy015B Bar Dia=8~100mm L=50~1000













Heat Resistant Copper Nickel Wire Curpothal 15 / Alloy 90 For Electric Blankets 0
