Name: | 0Cr25Al5 Heating Strip Wire For Industry Furnace Edge Brake Resistor | Wire Material: | 0Cr25Al5 |
---|---|---|---|
Supply State: | Wire Coil/ Strip Coil | Surface State: | Oxidized/Pickled/Polished/Bright |
Application: | Industry Furnace/ Edge Resistor/Brake Resistor | Resistance: | Customized As Customer Requirements |
High Light: | 0Cr25Al5 Heat Resistant Wire,Oxidized Heat Resistant Wire,Resistor Heat Resistant Wire Coil |
0Cr25Al5 Heating Strip Wire For Industry Furnace Edge Brake Resistor
0Cr25Al5
(Common Name: 0Cr25Al5,Aluchrom-O)
C | P | S | Mn | Si | Cr | Ni | Al | Fe | Other |
Max | |||||||||
0.06 | 0.025 | 0.025 | 0.70 | Max 0.60 | 23.0~26.0 | Max 0.60 | 4.5~6.5 | Bal. | - |
Temperature Factor of Electrical Resistivity
20℃ | 100℃ | 200℃ | 300℃ | 400℃ | 500℃ | 700℃ | 800℃ | 900℃ | 1000℃ | 1100℃ | 1200℃ | 1300℃ |
1 | 1.002 | 1.005 | 1.008 | 1.013 | 1.021 | 1.038 | 1.040 | 1.042 | 1.044 | 1.046 | 1.047 |
0Cr25Al5 is a iron-chromium-aluminium alloy (FeCrAl alloy) characterized by high resistance, low coefficient of electric resistance, high operating temperature, good corrosion resistance under high temperature.It is suitable for use at temperatures up to 1250°C.
Typical applications for OhmAlloy142B are used in electric ceramic cooktop,industrial furnace,heaters.
