HRB75 Thermal Spray Wire 1.6mm NiAl95/5 Nickel Aluminum Wire

I'm Online Chat Now
Certification
China Ohmalloy Material Co.,Ltd certification
China Ohmalloy Material Co.,Ltd certification
I search for Nichrome plate long time, and successfully bought it from Ohmalloy material. OHMALLOY provide real good service in alloy service and can always help me in finding the correct resistance alloy.

—— Mike Harness

OHMALLOY can provie me only 1kg Kovar alloy wire 1.0mm with short time, that is really amazing. Thanks

—— Janey

Really professional in thermocouple wire and cable, what i want just can get from OHMALLOY

—— Chris

Enamelled Constantan 0.08mm, i never expect to get only 2kg of it. But OHMALLOY supply it to me with good quality. God Jesus! Such a reliable supplier from china

—— Aaron

HRB75 Thermal Spray Wire 1.6mm NiAl95/5 Nickel Aluminum Wire

HRB75 Thermal Spray Wire 1.6mm NiAl95/5 Nickel Aluminum Wire
HRB75 Thermal Spray Wire 1.6mm NiAl95/5 Nickel Aluminum Wire HRB75 Thermal Spray Wire 1.6mm NiAl95/5 Nickel Aluminum Wire HRB75 Thermal Spray Wire 1.6mm NiAl95/5 Nickel Aluminum Wire

Large Image :  HRB75 Thermal Spray Wire 1.6mm NiAl95/5 Nickel Aluminum Wire Get Best Price

Product Details:
Place of Origin: China(Shanghai)
Brand Name: OHMALLOY
Certification: ISO
Model Number: TSW-NIAL-95
Payment & Shipping Terms:
Minimum Order Quantity: 15kg/spool
Price: negotiable
Packaging Details: DIN300,Plastic film inside, put into carton,packed into pallets or wooden case.
Delivery Time: 7-20 DAYS
Payment Terms: L/C, T/T,
Supply Ability: 50000KG/MONTH
Detailed Product Description
Material: Ni95% Al5% Diameter: 1.6mm,2.0mm
Package: 15kg/spool Application: Thermal Spray Coating
Spraying Way: Arc Spraying Typical Hardness: HRB75
Bond Strength: 10000 Psi Deposit Efficiency: 70%
High Light:

NiAl95/5 Nickel Aluminum Wire

,

1.6mm Nickel Aluminum Wire

,

HRB75 Thermal Spray Wire

1.6mm NiAl95/5 Nickel Aluminum wire thermal spray wire for arc spray systems


PRODUCT OVERVIEW

NiAl95/5 is a solid wire specifically designed for arc spray systems. It is self-bonding to most materials and requires minimal surface preparation. Bond strengths in excess of 9000 psi can be achieved on clean smooth surfaces. Roughening of the surface by machining, grit blasting or grinding can increase the bond strength up to 10,000 psi. NiAl95/5 exhibits good resistance to high temperature oxidation and abrasion, and excellent resistance to impact and bending. NiAl95/5 can be machined and ground to a finish of 5 micro inches. It is a self-bonding, one step material and is also suitable for the build-up and dimensional restoration of nickel-based alloys. PMET 885 is widely used as a bond coat for subsequent thermal spray topcoats and as a one-step build up material for dimensional restoration of aircraft engines.



TYPICAL DEPOSIT CHARACTERISTICS:

Þ Typical Hardness: HRB 75

Þ Bond Strength: 10000 psi

Þ Deposit Rate: 10 lbs/hr/100A

Þ Deposit Efficiency 70%

Þ Wire Coverage: 0.9 oz/ft2 / mil

Þ Surface Texture * Variable

Þ Machinability Good

Þ Coefficient of Thermal Exp. 7x10-6 in/in°F

(1000°F)

* Depends on air pressure used

SURFACE PREPARATION

Surface should be clean, white metal, with no oxides (rust), dirt, grease, or oil on the surface to be coated. Note: It is best not to handle surfaces after cleaning.

Recommended method of preparation is to grit blast with 24 mesh aluminum oxide, rough grind, or rough machine in a lathe.

APPLICATION

Þ Bond coat

Þ Dimensional restoration

SPECIFICATION

95Ni 5Al, PWA 36937 for PWA 271-37 Rev H,

GEAE C07-042 for GE SPM 70-49-38,

B50TF56-S11/CL A (Chem only), CFMI CP6039 for 70-48-14,

Honeywell FP5045, Type XV Nickel Aluminum


NOMINAL CHEMICAL COMPOSITION (wt%)

Ni Al Total Others
93.0 4.0-5.5 1.7 Max



RECOMMENDED SPRAY PARAMETERS:

Diameter Air Pressure Voltage Amperage Standoff
1/16” (1.6mm) *50-60 psi *29-30 *100-200 *3-6 in (8-15 cm)

* Parameters are Typical and may vary depending on equipment used. Contact your equipment manufacturer for optimum spray parameters



STANDARD SIZES & PACKAGING:

Diameter Packaging
1/16” (1.6mm) 15kg/spool



HRB75 Thermal Spray Wire 1.6mm NiAl95/5 Nickel Aluminum Wire 0

FAQ

1. What's the minimum quantity customer can order?

If we have your size in stock, we can provide any quantity you want.

If we do not have, for spool wire, we can produce 1 spool, about 2-3kg. For coil wire, 25kg.



2. How can you pay for small sample amount?

We have account, wire transfer for sample amount also ok.



3. Customer do not have express account. How will us arrange the delivery for sample order?

Just need to provide your address information, we will check the express cost, you can arrange the express cost together with sample value.



4. What's our payment terms?

We can accept LC T/T payment terms, it also depending on delivery and total amount. Let's talk more in details after getting your detailed requirements.



5. Do you provide free samples?

If you want several meters and we have stock of your size, we can provide, customer need to bear the International express cost.



6. What's our working time?

We will give you reply through email/phone Online contact tool within 24 hours. No matter working day or holidays.
