Anti - Oxidation Type E Thermocouple Wire , Thermocouple Lead Wire

Anti - Oxidation Type E Thermocouple Wire , Thermocouple Lead Wire
Anti - Oxidation Type E Thermocouple Wire , Thermocouple Lead Wire Anti - Oxidation Type E Thermocouple Wire , Thermocouple Lead Wire Anti - Oxidation Type E Thermocouple Wire , Thermocouple Lead Wire

Large Image :  Anti - Oxidation Type E Thermocouple Wire , Thermocouple Lead Wire Get Best Price

Product Details:
Place of Origin: China(Shanghai)
Brand Name: OHMALLOY
Certification: ISO9001-2008
Model Number: CUNI45
Payment & Shipping Terms:
Minimum Order Quantity: 10KG
Price: negotiable
Packaging Details: 20kg/coil, or DIN 160 or DIN 250
Delivery Time: 7-10 days
Payment Terms: , T/T, L/C
Supply Ability: 500000kg per month
Detailed Product Description
Material: TYPE E STATUS: Bright
DIAMETER: 0.71mm, 1.29mm, 1.62mm Spool: DIN 125, DIN 160, DIN200, DIN250
Application: Temperature Measuring Lead Time: 7-20 Days
High Light:

type k thermocouple wire

,

thermocouple extension wire

Anti - Oxidation Type E Thermocouple Wire , Thermocouple Lead Wire

  •
  • Type: K, E, J, T, N, etc
  • Style: bright or oxidized
  • Application: forming two hot electrodes of thermocouple or compensating cable
  • Place of Origin: Jiangsu, China (Mainland)
  • Brand Name: Thermocouple wire
  • Product Size: 0.05mm to 10.0mm
  • Delivery time: 7-20days which is according to quantity
  • Eco-friendly: Yes
  • MOQ: 1kgs
  • Trade term: FOB, EXW, CIF, CFR
  • Payment term: T/T, , L/C
  • Certificate: ISO,CQC ROHS
  • Making sample time: all type in stock
  • Advantage: high quality with high measuring accuracy, fast thermal response, high mechanical strength, long service lifetime, wide temp measuring range of -200-1300centigrade

Classification for thermocouple TYPE K wire

Anti - Oxidation Type E Thermocouple Wire , Thermocouple Lead Wire 0

  • Thermocouple level (high temperature level). This type of thermocouple wire is mainly suitable for thermocouple type K, J, E, T, N and L and other high temperature detection instrument, temperature sensor, etc.
  • Compensating wire level (low temperature level). This type of thermocouple wire is mainly suitable for compensating cable and extension wire of various thermocouples of type S, R, B, K, E, J, T, N and L, heating cable, control cable and so on.

Thermocouple variety and index for thermocouple TYPE K ROD



Thermocouple Variety and Index
Variety Type Measurement Range(°C)
NiCr-NiSi K –200–1300
NiCr-CuNi E –200–900
Fe-CuNi J –40–750
Cu-CuNi T –200–350
NiCrSi-NiSi N –200–1300
NiCr-AuFe0.07 NiCr-AuFe0.07 –270–0



Thermocouple type and grade for thermocouple TYPE K ROD



Thermocouple Type Grade Temperature Range(°C) Allowable Deviation
type K and type N I –40–1100 ±1.5°C or±0.4%t
II –40–1300 ±2.5°C or ±0.75%t
III –200–40 ±2.5°C or ±1.5%t
type E I –40–1100 ±1.5°C or ±0.4%t
II –40–1300 ±2.5°C or ±0.75%t
III –200–40 ±2.5°C or±1.5%t
type J I –40–750 ±1.5°C or ±0.4%t
II –40–750 ±2.5°C or ±0.75%t
type T I –40–350 ±0.5°C or± 0.4%t
II –40–350 ±1.0°C or± 0.75%t
III –200–40 ±1.0°C or± 1.5%t
NiCr-AuFe0.07 I –270–0 ±0.5°C
II ±1.0°C



Specification of alloy wires for thermocouple TYPE K ROD



Anode Cathode Diameter(mm) Maximum Temperature(°C)
name code name code long-time using short-time using
NiCr10(Chromel) KP NiSi3(Alumel) KN Φ0.3 700 800
Φ0.5 800 900
Φ0.8 Φ1.0 900 1000
Φ1.2 Φ1.6 1000 1100
Φ2.0 Φ2.5 1100 1200
NiCr14.2Si NP NiSi4 NN Φ3.2 1200 1300
NiCr10(Chromel) EP CuNi45(Copel) EN Φ0.3 Φ0.5 350 450
Φ0.8 Φ1.0 Φ1.2 450 550
Φ1.6 Φ2.0 550 650
Φ2.5 650 750
Φ3.2 750 900
Fe(Iron) JP CuNi45(Copel) JN Φ0.3 Φ0.5 300 400
Φ0.8 Φ1.0 Φ1.2 400 500
Φ1.6 Φ2.0 500 600
Φ2.5 Φ3.2 600 750
Cu(Copper) TP CuNi45(Copel) TN Φ0.2 Φ0.3 150 200
Φ0.5 Φ0.8 200 250
Φ1.0 Φ1.2 250 300
Φ1.6 Φ2.0 300 350
