Alloy C-276 Thermal Spray Wire Hrc 35 Typical Hardness 7000 Psi Bond Strength

Alloy C-276 Thermal Spray Wire Hrc 35 Typical Hardness 7000 Psi Bond Strength
Alloy C-276 Thermal Spray Wire Hrc 35 Typical Hardness 7000 Psi Bond Strength Alloy C-276 Thermal Spray Wire Hrc 35 Typical Hardness 7000 Psi Bond Strength Alloy C-276 Thermal Spray Wire Hrc 35 Typical Hardness 7000 Psi Bond Strength

Large Image :  Alloy C-276 Thermal Spray Wire Hrc 35 Typical Hardness 7000 Psi Bond Strength Get Best Price

Product Details:
Place of Origin: China(Shanghai)
Brand Name: OHMALLOY
Certification: ISO
Model Number: Alloy C276
Payment & Shipping Terms:
Minimum Order Quantity: 15kg/spool
Price: negotiable
Packaging Details: 15KG/SPOOL
Delivery Time: 7-20 DAYS
Payment Terms: L/C, T/T,
Supply Ability: 50000KG/MONTH
Detailed Product Description
Material: Alloy C276 Diameter: 1.6mm,2.0mm
Package: 15kg/spool Application: Pump Casings
Spraying Way: Arc Spraying Typical Hardness: HRC 35
Bond Strength: 7000 Psi Deposit Efficiency: 70%
High Light:

Metal Wire

,

Alloy Wire

Alloy C-276 Thermal Spray Wire Hrc 35 Typical Hardness 7000 Psi Bond Strength





PRODUCT OVERVIEW

Alloy C-276 is a high purity nickel-chrome-moly-tungsten (Alloy C-276) wire specifically designed for arc spraying. It produces dense, well-bonded coatings with good resistance to corrosion, and stress cracking in caustic, acidic and chloride mediums. It’s high hardness makes it very resistant to abrasion and metal wear.



TYPICAL DEPOSIT CHARACTERISTICS:

Þ Typical Hardness: HRC 35

Þ Bond Strength: 7000 psi

Þ Deposit Rate: 10 lbs/hr/100A

Þ Deposit Efficiency 70%

Þ Wire Coverage: 0.8 oz/ft2 / mil

Þ Surface Texture * Variable

* Depends on air pressure used



SURFACE PREPARATION

Surface should be clean, white metal, with no oxides (rust), dirt, grease, or oil on the surface to be coated. Note: It is best not to handle surfaces after cleaning.

Recommended method of preparation is to grit blast with 24 mesh aluminum oxide, rough grind, or rough machine in a lathe.



APPLICATION

Þ Corrosion resistance

Þ Pump casings

Þ valves



SPECIFICATION

Alloy C-276



NOMINAL CHEMICAL COMPOSITION (wt%)

Ni Cr Mo Fe W
60.0 15.0 16.0 5.0 4.0



RECOMMENDED SPRAY PARAMETERS:

Diameter Air Pressure Voltage Amperage Standoff
1/16” (1.6mm) *50-60 psi *29-32 *100-300 *3-8 in (8-20 cm)



STANDARD SIZES & PACKAGING:

Diameter Packaging
1/16” (1.6mm) 15kg/spool



Alloy C-276 Thermal Spray Wire Hrc 35 Typical Hardness 7000 Psi Bond Strength 0
