Product Details:
Payment & Shipping Terms:
|
| Material: | 1J79 | Brand: | Ohmalloy |
|---|---|---|---|
| Color: | Primary Color | Wire Diameter: | 0.02mm-0.8mm |
| Delivery Time: | 7-20days | Package: | Wooden Box |
| Sample: | Free Sample | Alloy Or Not: | Is Alloy |
| Highlight: | weaving wire mesh,shielding Wire mesh |
||
1J79 soft magnetic wire mesh,OEM types of weave,for shielding
Normal composition
| Ni | 78.5~80.0 | Fe | Bal. | Mn | 0.6~1.1 | Si | 0.3~0.5 |
| Mo | 3.8~4.1 | Cu | ≤0.2 | ||||
| C | ≤0.03 | P | ≤0.02 | S | ≤0.02 |
| Yield strength | Tensile Strength | Elongation |
| Mpa | Mpa | % |
| 980 | 1030 | 3~50 |
| Density (g/cm3) | 8.6 |
| Electrical resistivity at 20℃(Ωmm2/m) | 0.55 |
| Coefficient of linear expansion(20℃~200℃)X10-6/℃ | 10.3~11.5 |
| Saturation magnetostriction coefficient λθ/ 10-6 | 2.0 |
| Curie point Tc/ ℃ | 450 |
|
The magnetic properties of alloys with high permeability in weak fields |
|||||||
| 1J79 | Initial permeability | Maximum permeability | Coercivity | Saturation magnetic induction intensity | |||
|
Сold-rolled strip/ sheet. Thickness, mm |
μ0.08/ (mH/m) | μm/ (mH/m) | Hc/ (A/m) | BS/ T | |||
| ≥ | ≤ | ||||||
| 0.01 mm | 17.5 | 87.5 | 5.6 |
0.75 |
|||
| 0.1~0.19 mm | 25.0 | 162.5 | 2.4 | ||||
| 0.2~0.34 mm | 28.0 | 225.0 | 1.6 | ||||
| 0.35~1.0 mm | 30.0 | 250.0 | 1.6 | ||||
| 1.1~2.5 mm | 27.5 | 225.0 | 1.6 | ||||
| 2.6~3.0 mm | 26.3 | 187.5 | 2.0 | ||||
| cold drawn wire | |||||||
| 0.1 mm | 6.3 | 50 | 6.4 | ||||
| Bar | |||||||
| 8-100 mm | 25 | 100 | 3.2 | ||||
