Product Details:
Payment & Shipping Terms:
|
| Material:: | Cu/CuNi | Insulation:: | Silicone Rubber |
|---|---|---|---|
| Jacket:: | Silicone Rubber | Diameter:: | 0.12-1.5mm |
| Conductor Diameter: | Conductor Diameter | Measuring Temperature Tolerance:: | + / - 1.1 ℃ To + / - 0.4% |
| Color:: | Positive Yellow, Negative White, Sheath Yellow (other Colors Of Insulating Layer Are Acceptable) | ||
| High Light: | thermocouple bare wire,thermocouple extension wire |
||
Conductor material:
| material | Chemical composition (%) | ||||
| Ni | Al | Cu | Si | Mn | |
| TP: pure copper | 100 | ||||
| TN: CuNi | 0.6 | Bal | |||
Conductor structure
| Conductor diameter | 0.3mm*7 |
| Insulation | silicone rubber200℃ |
| Insulation thickness | 0.35mm |
| Inner shield | PTFE film +SS304 woven wire |
| Sheath material | silicone rubber200℃ |
| Sheath thickness | 0.5mm |
| Section size: | 4.5mm |
| Each meter weighs: | 10kg/100meter |
Thermocouple variety and index
| Long-term max standing temperature | 260℃ |
| Short-term max standing temperature | 300℃ |
Available conductor alloy grade as follows:
| NiCr60/15 | CuNi44 | CuNi23 | OCr25Al5 | OCr21Al6 |
| Nickel 200 | Nickel 201 | Nickel 212 | Tinned copper wire | CuNi6 |
| CuNi10 | NiCr35/20 | NiCr AA | Inconel 600 | Inconel 625 |
Available color: White, black, yellow, red, brown, green, blue, purple
Applications:Widely used in internal or external wiring requiring high heat-resistance or high speed transfer circuit.
Conductors can also be provided with stranded wire, dimensions such as 0.2mm*7, 0.3mm*7, 0.2mm*19.Ohmalloy aslo can make all kinds of insulation resistance wire on customer’s special requirement.
Thermocouple variety and index
Thermocouple Variety and Index |
||
Variety |
Type |
Measurement Range(°C) |
NiCr-NiSi |
K |
-200-1300 |
NiCr-CuNi |
E |
-200-900 |
Fe-CuNi |
J |
-40-750 |
Cu-CuNi |
T |
-200-350 |
NiCrSi-NiSi |
N |
-200-1300 |
NiCr-AuFe0.07 |
NiCr-AuFe0.07 |
-270-0 |
