ANSI Thermocouple Type K Wire Copper Constantan Compensation Cable

Name: ANSI Thermocouple Type K Wire Copper Constantan Compensation Cable
Brand: OHMALLOY
SKU: Type K Wire KCB
Rating: 4.8 (180 reviews)

Large Image : ANSI Thermocouple Type K Wire Copper Constantan Compensation Cable Get Best Price

Product Details:

Place of Origin:	China(Shanghai)
Brand Name:	OHMALLOY
Certification:	ISO9001-2008
Model Number:	Type K Wire KCB

Payment & Shipping Terms:

Minimum Order Quantity:	500 meters
Price:	negotiable
Packaging Details:	100m/spool, 305m/spool, 1000ft/spool, 1000m/spool
Delivery Time:	7 -15 days
Payment Terms:	L/C, T/T, Paypal,
Supply Ability:	500000 meters per month

Contact Now

Detailed Product Description

Type:

Wire

Insulation:

Bare

Accuracy:

Class 1

Color:

ANSI Code, IEC Code, GB/T Standard

High Light:

ANSI Thermocouple Type K Wire

Copper Constantan Compensation Cable

Class 1 Thermocouple Type K Wire

Thermocouple Type K Wire KCB Copper Constantan Compensation Cable Cheap Price Class 1 Accuracy

TYPE KCB (Cu vs CuNi40) is used for making cable which can be extension for type K thermocouple. The cost is cheaper a lot than Kx type.

1. Chemical Composition

Material	Chemical composition (%)
Material	Ni	Fe	Si	Cu	Al
KPCB				100
KNCB	40			60

2. Physical properties and Mechanical properties

Material	Density(g/cm³)	Melting point℃)	Tensile Strength(Mpa)	Volume resistivity(μΩ.cm)	Elongation rate (%)
KPCB	8.9	1450	>190	<1.8(20℃)	>30
KNCB	8.9	1450	>390	<50(20℃)	>25

3. EMF Value range at different temperature

Material	EMF value Vs Pt(μV)
	1^st tolerance		2^nd tolerance
	100℃	200℃	100℃	200℃
KPCB	4052-4140	8094-8182	4008-4184	8050-8226
KNCB

Package

ANSI Thermocouple Type K Wire Copper Constantan Compensation Cable 1

FAQ
1. What's the minimum quantity customer can order?

If we have your size in stock, we can provide any quantity you want.

If we do not have, for spool wire, we can produce 1 spool, about 2-3kg. For coil wire, 25kg.

2. How can you pay for small sample amount?

We have account, wire transfer for sample amount also ok.

3. Customer do not have express account. How will us arrange the delivery for sample order?

Just need to provide your address information, we will check the express cost, you can arrange the express cost together with sample value.

4. What's our payment terms?

We can accept LC T/T payment terms, it also depending on delivery and total amount. Let's talk more in details after getting your detailed requirements.

5. Do you provide free samples?

If you want several meters and we have stock of your size, we can provide, customer need to bear the International express cost.

6. What's our working time?

We will give you reply through email/phone Online contact tool within 24 hours. No matter working day or holidays.
