Product Details:
Payment & Shipping Terms:
|
| UNS:: | NO6600 | Surface: | Bright |
|---|---|---|---|
| Werkstoff Nr.: | Nr.2.4816 | Power Or Not: | Not |
| Type: | Seamless | Shape: | Tube |
| Thickness: | 0.01~50mm | Craft: | Cold Drawing |
| OD: | 0.20~360mm | ||
| High Light: | Bright Inconel 600 Tube,UNS N06600 Inconel 600 Tube,Seamless Inconel 600 Tube |
||
Inconel 600 is a nonmagnetic nickel-chromium alloy with excellent resistance to oxidation and other forms of high temperature corrosion. This alloy also has excellent mechanical properties and presents desirable combination of high strength and good workability. Used for furnace and chemical-treatment components, in food processing, in nuclear engineering, and for engine and airframe components.
Chemical Composition
| Grade | Ni% | Mn% | Fe% | Si% | Cr% | C% | Cu% | S% |
| Alloy600 | Min72.0 | Max1.0 | 6.0-10.0 | Max0.50 | 14-17 | Max0.15 | Max0.50 | Max0.015 |
Specifications
| Grade | British Standard | Werkstoff Nr. | UNS |
| Alloy 600 | BS 3075 (NA14) | 2.4816 | N06600 |
Strong Physical Properties
| Grade | Density | Melting Point |
| Alloy 600 | 8.47 g/cm3 | 1370°C-1413 ° |
Mechanical Properties
| Alloy State | Tensile Strength | Yield Strength | Elongation | Brinell Hardness (HB) |
| Annealing Treatment | 550 N/mm² | 240 N/mm² | 30% | ≤195 |
| Solution Treatment | 500 N/mm² | 180 N/mm² | 35% | ≤185 |
Welding of Inconel 600
Any traditional welding procedures can be used to weld Inconel 600 to similar alloys or other metals. Before welding, preheating is needed and also any stain, dust or mark should be cleared by steel wire brush. About 25mm width to welding edge of base metal should be polished to bright.
Recommend filler wire regarding welding Inconel 600: ENiCr-3
FAQ
1. What's the minimum quantity customer can order?
If we have your size in stock, we can provide any quantity you want.
If we do not have, for spool wire, we can produce 1 spool, about 2-3kg. For coil wire, 25kg.
2. How can you pay for small sample amount?
We have account, wire transfer for sample amount also ok.
3. Customer do not have express account. How will us arrange the delivery for sample order?
Just need to provide your address information, we will check the express cost, you can arrange the express cost together with sample value.
4. What's our payment terms?
We can accept LC T/T payment terms, it also depending on delivery and total amount. Let's talk more in details after getting your detailed requirements.
5. Do you provide free samples?
If you want several meters and we have stock of your size, we can provide, customer need to bear the International express cost.
6. What's our working time?
We will give you reply through email/phone Online contact tool within 24 hours. No matter working day or holidays.
