2mm Dia Pure Titanium Metal Wire Grade 2 For Industry

I'm Online Chat Now
Certification
China Ohmalloy Material Co.,Ltd certification
China Ohmalloy Material Co.,Ltd certification
I search for Nichrome plate long time, and successfully bought it from Ohmalloy material. OHMALLOY provide real good service in alloy service and can always help me in finding the correct resistance alloy.

—— Mike Harness

OHMALLOY can provie me only 1kg Kovar alloy wire 1.0mm with short time, that is really amazing. Thanks

—— Janey

Really professional in thermocouple wire and cable, what i want just can get from OHMALLOY

—— Chris

Enamelled Constantan 0.08mm, i never expect to get only 2kg of it. But OHMALLOY supply it to me with good quality. God Jesus! Such a reliable supplier from china

—— Aaron

2mm Dia Pure Titanium Metal Wire Grade 2 For Industry

2mm Dia Pure Titanium Metal Wire Grade 2 For Industry
2mm Dia Pure Titanium Metal Wire Grade 2 For Industry
video play

Large Image :  2mm Dia Pure Titanium Metal Wire Grade 2 For Industry Get Best Price

Product Details:
Place of Origin: China(Shanghai)
Brand Name: OHMALLOY
Certification: ISO,Rohs
Model Number: Gr1
Payment & Shipping Terms:
Minimum Order Quantity: 10KG
Price: negotiable
Packaging Details: Plastics Spool,wooden case outside
Detailed Product Description
Size: 2mm Color: Silvery
Surface: Bright Density: 4.51
Application: Industrial,surgical Implant,aerospace
High Light:

2mm Pure Titanium Metal Wire

,

Industrial Pure Titanium Metal Wire

,

Grade 2 Titanium Wire

2mm Dia. Pure Titanium metal wire Ti Gr2 Grade 2



Grade: GR1 GR2 GR3 GR5 GR7 GR9 GR12 etc.
Standard: ASTM B265
Size: 0.3mm,0.5mm,0.7mm
Condition: M/Y annealed
Machining technics: cold rolled, hot rolled
Delivery time: 20 days
Ti purity: GR1 99.6%min
Certificate: ISO 9001:2008
Package: wooden case
Min: 10kg
Payment: T/T



Chemical Request

  N C H Fe O Al V Pa Mo Ni Ti
Gr 1 0.03 0.08 0.015 0.20 0.18 / / / / / bal
Gr 2 0.03 0.08 0.015 0.30 0.25 / / / / / bal
Gr 5 0.05 0.08 0.015 0.40 0.20 5.5~6.75 3.5~4.5 / / / bal
Gr 7 0.03 0.08 0.015 0.30 0.25 / / 0.12~0.25 / / bal
Gr 9 0.03 0.08 0.015 0.25 0.15 2.5~3.5 2.0~3.0 / / / bal
Gr12 0.03 0.08 0.015 0.30 0.25 / / / 0.2~0.4 0.6~0.9 bal



Mechanical Properties of Supplier 0.3mm Ti 4Al6V titanium foil electronic use

Grade Tensil strength(min) Yeild strength(min) Elongation (%)
Ksi MPa Ksi MPa
1 35 240 20 138 24
2 50 345 40 275 20
5 130 895 120 828 10
7 50 345 40 275 20
9 90 620 70 438 15
12 70 438 50 345

18



Application Supplier 0.3mm Ti 4Al6V titanium foil electronic use

(1). Grade 1 can be used in the drawing parts for its good elongation and excellent corrosion-resistance.

(2). Grade 2 is used most widely in the commercially pure titanium

(3). Grade 3 is almost used in pressure,vessel.

(4). Grade 4 can be used in some fittings parts and fastening pieces, but for complex shape need 300 degree

celsius to form.

(5). Alloy grade 5(Ti-6Al-4V) widely used in the titanium alloys because of its comprehensive mechanical and

chemical properties.

(6). Alloy grade 7 add little palladium in cp titanium and it has the most excellent corrosion-resistance,of

course it costs higher.

(7). Alloy grade 9(Ti-3Al-2.5V) is the most widely used in the golf clubs and bicycle girders.

(8). Alloy grade 23, ELI(extra low interstitial),can be used in the medical appliance.



2mm Dia Pure Titanium Metal Wire Grade 2 For Industry 02mm Dia Pure Titanium Metal Wire Grade 2 For Industry 12mm Dia Pure Titanium Metal Wire Grade 2 For Industry 2


FAQ

1. What's the minimum quantity customer can order?

If we have your size in stock, we can provide any quantity you want.

If we do not have, for spool wire, we can produce 1 spool, about 2-3kg. For coil wire, 25kg.



2. How can you pay for small sample amount?

We have account, wire transfer for sample amount also ok.



3. Customer do not have express account. How will us arrange the delivery for sample order?

Just need to provide your address information, we will check the express cost, you can arrange the express cost together with sample value.



4. What's our payment terms?

We can accept LC T/T payment terms, it also depending on delivery and total amount. Let's talk more in details after getting your detailed requirements.



5. Do you provide free samples?

If you want several meters and we have stock of your size, we can provide, customer need to bear the International express cost.



6. What's our working time?

We will give you reply through email/phone Online contact tool within 24 hours. No matter working day or holidays.
