Be Cu Rod Beryllium Copper C17200 C17300 C17500 C17510 CuCo1Ni1Be

Be Cu Rod Beryllium Copper C17200 C17300 C17500 C17510 CuCo1Ni1Be
Be Cu Rod Beryllium Copper C17200 C17300 C17500 C17510 CuCo1Ni1Be Be Cu Rod Beryllium Copper C17200 C17300 C17500 C17510 CuCo1Ni1Be Be Cu Rod Beryllium Copper C17200 C17300 C17500 C17510 CuCo1Ni1Be Be Cu Rod Beryllium Copper C17200 C17300 C17500 C17510 CuCo1Ni1Be Be Cu Rod Beryllium Copper C17200 C17300 C17500 C17510 CuCo1Ni1Be Be Cu Rod Beryllium Copper C17200 C17300 C17500 C17510 CuCo1Ni1Be

Large Image :  Be Cu Rod Beryllium Copper C17200 C17300 C17500 C17510 CuCo1Ni1Be Get Best Price

Product Details:
Place of Origin: Shanghai
Brand Name: Ohmalloy/OEM
Certification: CCC,ROHS
Model Number: SP-Ohmalloy17200
Payment & Shipping Terms:
Minimum Order Quantity: 20KG
Price: 29.8USD/KG
Packaging Details: Coil,paper wrapped,carton outside
Delivery Time: 5-8 working days after payment confirmed
Payment Terms: L/C, T/T, , MoneyGram,paypal
Supply Ability: 50 Tons per month
Detailed Product Description
Features: Good Mechanical, Physical And Chemical Properties Name: Beryllium Copper
Material: C17200 Elastic Modulus: 128 GPa
Conductivity: 18%(IACS) Composition: Cu 97% Be 2% Ni+Fe+Co≤0.6%
High Light:

C17300 Beryllium Copper Rod

,

Wear Resistance Beryllium Copper Rod

,

C17510 Beryllium Copper Round Bar

C17200 Beryllium Copper Becu Strip / Bar


Beryllium copper is a supersaturated solid solution copper-based alloy, a copper alloy with bismuth as the main alloying element, also known as beryllium bronze.

Features:
Beryllium copper is an alloy with good mechanical, physical and chemical properties. After quenching, it has high strength, elasticity, wear resistance, fatigue resistance and heat resistance, with feature of high conductivity,thermal conductivity, cold resistance and non-magnetic, no sparks when hitting, easy to weld and excellent corrosion resistance in the atmosphere, fresh water and seawater.

Usage:
Casting beryllium bronze: (Cu-2Be-0.5Co-0.3Si, Cu-2.6Be-0.5Co-0.3Si, Cu-0.5Be-2.5Co, etc.) For explosion-proof tools, various molds (inner inserts for plastic injection molding dies, integral cavities for blow molds, automotive molds), bearings, bushings, bushings, gears and various electrodes
Processing beryllium bronze: (Cu-2Be-0.3Ni, Cu-1.9Be-0.3Ni-0.2Ti) is mainly used as a variety of advanced elastic components, especially requiring good conductivity, corrosion resistance, wear resistance, cold resistance, various no magnetic components, used as a large number of bellows, diaphragms, bellows, micro switches, etc.

Chemical Composition(%)

Brand Be Co Ni Co+Ni Co+Ni+Fe Pb Cu Other
C17200 1.8-2.0 / / Min 0.2 Max 0.6 Max 0.2 Bal. Max 0.05


Technical Specification



Density

Hardness after Quenching Tensile Strength Yield Strength (0.2%) Elastic Modulus



Conductivity

Thermal Conductivity

at 20℃

g/cm HRC MPa MPa GPa IACS w/m.k
8.3 ≥36-42 ≥1000 1035 128 18% 105


C17200 Beryllium Copper Becu Strip / Bar

Our Package
C17200 Beryllium Copper Becu Strip / Bar


C17200 Beryllium Copper Becu Strip / Bar

C17200 Beryllium Copper Becu Strip / Bar

RFQ

1. What's the minimum quantity customer can order?
If we have your size in stock, we can provide any quantity you want.
If we do not have, for spool wire, we can produce 1 spool, about 2-3kg. For coil wire, 25kg.

2. How can you pay for small sample amount?
We have account, wire transfer for sample amount also ok.
3. Customer do not have express account. How will us arrange the delivery for sample order?
Just need to provide your address information, we will check the express cost, you can arrange the express cost together with sample value.
4. What's our payment terms?
We can accept LC T/T payment terms, it also depending on delivery and total amount. Let's talk more in details after getting your detailed requirements.
5. Do you provide free samples?
If you want several meters and we have stock of your size, we can provide, customer need to bear the International express cost.
6. What's our working time?
We will give you reply through email/phone Online contact tool within 24 hours. No matter working day or holidays.
