Product Details:
Payment & Shipping Terms:
|
| Resistivity(μΩ.m): | 0.48 | Shape: | Foil |
|---|---|---|---|
| Working Temperature: | 400℃ | Application: | Strain Gauge |
| Tensile Strength: | 420Mpa | Density (g/cm3): | 8.9 |
| High Light: | copper alloys,copper nickel alloy |
||
Strain Gauge Copper Nickel Alloys , Precision Resistance Constantan Foil 0.005 x 100 mm
OhmAlloy49(Resistance heating wire and resistance wire)
(Common Name:CuNi44,NC50.Cuprothal, Alloy 294, Cuprothal 294, Nico, MWS-294, Cupron, Copel, Alloy 45, Neutrology, Advance, CuNi 102, Cu-Ni 44, Konstantan,constantan.)
Grade: Constantan Resistance Alloy (Ohmalloy49)
Chemical Composition: Ni:44% Cu: Rest%
Max. continuous service temp. of element(°C) :400degrees
Resistivity at 20ºC(μΩ·m):0.49 ohm mm2/m
Density(g/cm3): 8.9
NiCr series: CuNi1;CuNi2;CuNi6;CuNi8;CuNi10;CuNi14;CuNi19;
CuNi23;CuNi30;CuNi34;CuNi40(Constantan);Manganin
Normal composition%
| Nickel | 44 | Manganese | 1 |
| Copper | Bal. |
Typical Mechanical properties(1.0mm)
| Yield strength | Tensile Strength | Elongation |
| Mpa | Mpa | % |
| 250 | 420 | 25 |
Typical Physical properties
| Density (g/cm3) | 8.9 |
| Electrical resistivity at 20℃ (Ωmm2/m) | 0.49 |
| Temperature factor of resistivity(20℃~600℃)X10-5/℃ | -6 |
| Conductivity coefficient at 20℃ (WmK) | 23 |
| EMF vs Cu(μV/℃ )(0~100℃ ) | -43 |
| Melting point (℃) | 1280 |
| Max continuous operating temperature in air (℃) | 400 |
| Magnetic properties | non-magnetic |
Corrosion resistance performance
| Alloys | Working In atmosphere at 20℃ | Working at max temperature 200℃ | |||||
|
Air and oxygen contain |
gases with Nitrogen |
gases with sulfur |
gases with sulfur |
carburization | |||
| OhmAlloy49 | good | good | good | good | bad | good | |
Style of supply
| Alloys Name | Type | Dimension | ||
| OhmAlloy49W | Wire | D=0.03mm~8mm | ||
| OhmAlloy49R | Ribbon | W=0.4~40 | T=0.03~2.9mm | |
| OhmAlloy49S | Strip | W=8~200mm | T=0.1~3.0 | |
| OhmAlloy49F | Foil | W=6~120mm | T=0.003~0.1 | |
| OhmAlloy49B | Bar | Dia=8~100mm | L=50~1000 | |
FAQ
1. What's the minimum quantity customer can order?
If we have your size in stock, we can provide any quantity you want.
If we do not have, for spool wire, we can produce 1 spool, about 2-3kg. For coil wire, 25kg.
2. How can you pay for small sample amount?
We have account, wire transfer for sample amount also ok.
3. Customer do not have express account. How will us arrange the delivery for sample order?
Just need to provide your address information, we will check the express cost, you can arrange the express cost together with sample value.
4. What's our payment terms?
We can accept LC T/T payment terms, it also depending on delivery and total amount. Let's talk more in details after getting your detailed requirements.
5. Do you provide free samples?
If you want several meters and we have stock of your size, we can provide, customer need to bear the International express cost.
