Product Details:
Payment & Shipping Terms:
|
| Resistivity: | 1.35μΩ.m | Shape: | Strip |
|---|---|---|---|
| Surface: | Bright | Application: | Resistor |
| Density: | 7.25 | Elongation: | 23min |
| Highlight: | heating wire,high temperature alloys |
||
D Strip FeCrAl Alloy 0.5mm x 30mm Bright Working For Neutral Grounding Resistors
OhmAlloy142B
(Common Name:0Cr25Al5,Aluchrom-O)
OhmAlloy142B is a iron-chromium-aluminium alloy (FeCrAl alloy) characterized by high resistance, low coefficient of electric resistance, high operating temperature, good corrosion resistance under high temperature.It is suitable for use at temperatures up to 1250°C.
Typical applications for OhmAlloy142B are used in electric ceramic cooktop,industrial furnace,heaters.
General Information
Resistance wire is a type of high resistance electrical wire. The wire resists the flow of electricity, and converts the electrical energy into heat.
Application for resistance wire includes resistors, heating elements, electric heaters, electric ovens, toasters, and many more.
Nichrome, a non-magnetic alloy of nickel and chromium, is commonly used to make resistance wire because it has a high resistivity and resistance to oxidation at high temperatures. When used as a heating element, resistance wire is usually wound into coils. One difficulty in using nichrome wire is that common electrical solder will not stick to it, so the connections to the electrical power must be made using other methods such as crimp connectors or screw terminals.
FeCrAl, a family of iron-chromium-aluminum alloys ( APM, A-1, D and AF etc.) used in a wide range of resistance and high-temperature applications is also used in the form of resistance wires.
Normal composition%
| C | P | S | Mn | Si | Cr | Ni | Al | Fe | Other |
| Max | |||||||||
| 0.06 | 0.025 | 0.025 | 0.70 | Max 0.6 | 20.5~23.5 | Max 0.60 | 4.2~5.3 | Bal. | - |
Typical Mechanical properties(1.0mm)
| Yield strength | Tensile Strength | Elongation |
| Mpa | Mpa | % |
| 485 | 670 | 23 |
FAQ
Q1.Do you attend exhibition every year?
A .Yes
Q2.Is there any discount of the nickel wire?
A. Yes. Bigger quantity will get a discount.
Q3.Information needed if I want a quotation?
A Name, Standard, Material Grade(Chemical Composition), Size Quantity, Weight.
Q4. Can we visit your company/factory before place the order?
A. Yes. Welcome anytime
Q5: How does your factory do regarding quality control?
A. Quality is priority. We always attach great importance to quality controlling from beginning to end.
