Resistivity: | 1.12μΩ.m | Shape: | Strip |
---|---|---|---|
Surface: | Bright | Density (g/cm3): | 8.2 |
Elongation: | 35% | State: | Annealled |
Yield Strength: | 430 | ||
Highlight: | nichrome resistance wire,nickel chromium resistance wire |
CrNi30/70 Nichrome Heating Coil 35% Elongation 430 Yield Strength
OhmAlloy118
(Common Name:Ni70Cr30, Nikrothal 70, N7, HAI-NiCr 70, Chromel 70/30, Resistohm 70, Balco,Tophet 30,Cronix 70,Alloy 710,Stablohm 710)
OhmAlloy118 is a nickel-chromium alloy (NiCr alloy) characterized byHigh resistivity, good oxidation resistance,very good form stability,good ductility and excellent weldability. It is suitable for use at temperatures up to 1250°C.
Characteristics:
1) The highest working temperature up to 1250 degree.
2) Higher elongation
3) More stable mechanical properties
4) Better ductility and weldability.
Applications
Nichrome alloy resistance strip Ni70Cr30 is widely used for making electric heating elements in home appliances and industrial furnaces. Typical applications are flat irons, ironing machines, water heaters, plastic moulding dies, soldering irons, metal sheathed tubular elements and cartridge elements.
Main grades and properties
Type | Cr20Ni80 | Cr15Ni60 | Cr30Ni70 | Cr20Ni35 | Cr20Ni30 | |
Main chemical composition | Ni | Rest | 55.0~61.0 | Rest | 34.0~37.0 | 30.0~34.0 |
Cr | 20.0~23.0 | 15.0~18.0 | 28.0~31.0 | 18.0~21.0 | 18.0~21.0 | |
Fe | ≤1 | Rest | ≤1 | Rest | Rest | |
Maximal Temperature(℃) | 1200 | 1150 | 1250 | 1100 | 1100 | |
Resistance Temperature correction coefficient.(CT) | 1.09±0.05 | 1.11±0.05 | 1.18±0.05 | 1.04±0.05 | 1.06±0.05 | |
Melting point (℃) | 1400 | 1390 | 1380 | 1390 | 1390 | |
Resistivityρ20℃(10-6Ω.m) | 800℃ | 1.008 | 1.078 | 1.028 | 1.188 | 1.173 |
1000℃ | 1.014 | 1.095 | 1.033 | 1.219 | 1.201 | |
1200℃ | 1.025 | 1.043 | ||||
Fast life value | Tem.(℃) | 1175 | 1100 | 1200 | 1050 | 1050 |
hour(h) | ≥110 | ≥100 | ≥110 | ≥100 | ≥100 | |
Specific gravity(g/cm3) | 8.40 | 8.2 | 8.1 | 7.90 | 7.90 | |
Elongation(%) | ≥25 | ≥25 | ≥20 | ≥20 | ≥20 | |
Thermal(kj/m.h.℃) | 60.3 | 45.2 | 45.2 | 43.8 | 43.8 | |
Specific heat(20℃)j/g.℃ | 0.440 | 0.494 | 0.461 | 0.500 | 0.500 | |
Extend strength(20~1000℃)α*10-6℃ | 18.0 | 17.0 | 17.1 | 19.0 | 19.0 | |
Tensile strength(kg/mm2) | >85 | >85 | >85 | >85 | >85 | |
Repeatedly bending(F/R) | >12 | >12 | >12 | >12 | >12 | |
Microstructure | Austenitic | Austenitic | Austenitic | Austenitic | Austenitic |
FAQ:
1. What's the minimum quantity customer can order?
If we have your size in stock, we can provide any quantity you want.
If we do not have, for spool wire, we can produce 1 spool, about 2-3kg. For coil wire, 25kg.
2. How can you pay for small sample amount?
We have account, wire transfer for sample amount also ok.
3. Customer do not have express account. How will us arrange the delivery for sample order?
Just need to provide your address information, we will check the express cost, you can arrange the express cost together with sample value.
4. What's our payment terms?
We can accept LC T/T payment terms, it also depending on delivery and total amount. Let's talk more in details after getting your detailed requirements.
5. Do you provide free samples?
If you want several meters and we have stock of your size, we can provide, customer need to bear the International express cost.
6. What's our working time?
We will give you reply through email/phone Online contact tool within 24 hours. No matter working day or holidays.
1) Pass ISO9001 and SGS certification.
2) Samples free available.
3) OEM service.
4) Manufacturer test certificate will be provided If necessary.
5) Good packing methods to keep goods safe.
6) Choose safe,quick,price reasonable forwarder to transport for our customers.
7) Short delivery time
Normal composition%
C | P | S | Mn | Si | Cr | Ni | Al | Fe | Other |
Max | |||||||||
0.05 | 0.02 | 0.015 | 0.60 | 0.75~1.60 | 28.0~31.0 | Bal. | Max 0.50 | Max 1.0 | - |
Typical Mechanical properties(1.0mm)
Yield strength | Tensile Strength | Elongation |
Mpa | Mpa | % |
430 | 820 | 30 |
Typical Physical properties
Density (g/cm3) | 8.2 |
Electrical resistivity at 20℃(Ωmm2/m) | 1.18 |
Conductivity coefficient at 20℃ (WmK) | 14 |
Coefficient of thermal expansion | |
Temperature | Coefficient of Thermal Expansion x10-6/℃ |
20 ℃- 1000℃ | 17 |
Specific heat capacity | |
Temperature | 20℃ |
J/gK | 0.46 |
Melting point (℃) | 1380 |
Max continuous operating temperature in air (℃) | 1250 |
Magnetic properties | non-magnetic |
Temperature Factors Of Electrical Resistivity
20℃ | 100℃ | 200℃ | 300℃ | 400℃ | 500℃ | 600℃ |
1 | 1.007 | 1.016 | 1.028 | 1.038 | 1.044 | 1.036 |
700℃ | 800℃ | 900℃ | 1000℃ | 1100℃ | 1200℃ | 1300℃ |
1.03 | 1.028 | 1.029 | 1.033 | 1.037 | 1.043 | - |
Style of supply
Alloys Name | Type | Dimension | ||
OhmAlloy118W | Wire | D=0.03mm~8mm | ||
OhmAlloy118R | Ribbon | W=0.4~40 | T=0.03~2.9mm | |
OhmAlloy118S | Strip | W=8~250mm | T=0.1~3.0 | |
OhmAlloy118F | Foil | W=6~120mm | T=0.003~0.1 | |
OhmAlloy118B | Bar | Dia=8~100mm | L=50~1000 |
