Oxidized Ni80cr20 Nichrome Alloy Electric Heating Elements Resistance Strip For Furnance

China Oxidized Ni80cr20 Nichrome Alloy Electric Heating Elements Resistance Strip For Furnance supplier
Oxidized Ni80cr20 Nichrome Alloy Electric Heating Elements Resistance Strip For Furnance supplier Oxidized Ni80cr20 Nichrome Alloy Electric Heating Elements Resistance Strip For Furnance supplier Oxidized Ni80cr20 Nichrome Alloy Electric Heating Elements Resistance Strip For Furnance supplier

Large Image :  Oxidized Ni80cr20 Nichrome Alloy Electric Heating Elements Resistance Strip For Furnance

Product Details:

Place of Origin: CHINA
Brand Name: OHMALLOY
Certification: ISO CE ROSH
Model Number: Ni80Cr20

Payment & Shipping Terms:

Minimum Order Quantity: 100KG
Packaging Details: WOODEN CASE
Delivery Time: 15WORKDAYS
Payment Terms: L/C, T/T, Western Union
Supply Ability: 2000KG/WEEK
Contact Now
Detailed Product Description
Shape: Strip Application: Heating Elements
Chemical Composition: Nichrome Material: Nickel Chrome Alloy
Dimensions: Customzied Surface: Acid Pickled
Product Name: Nichrome Strip Ni80Cr20 Nickel Chrome Alloy

Ni80Cr20 is a nickel-chromium alloy (NiCr alloy) characterized by high resistivity, good oxidation resistance and very good form stability. It is suitable for use at temperatures up to 1200°C,and hold a superior service life compared to Iron chromium alumium alloys


Products Details

1). Chemical composition(%)

C P S Mn Si Cr Ni Al Fe Other
0.03 0.02 0.15 0.60 0.75-1.60 20.0~23.0 Bal. Max0.5 Max1.0 _



2).Typical Mechanical properties(1.0mm)

Yield strength Tensile Strength Elongation
Mpa Mpa %
420 810 30


3).Typical Physical properties

Density (g/cm3) 8.4
Electrical resistivity at 20ºC(Ωmm2/m) 1.09
Conductivity coefficient at 20ºC (WmK) 15



4).Coefficient of Thermal Expansion

Temperyure Coefficient of Thermal Expansion x10-6/ºC
20 ºC- 1000ºC 20



5).Specific Heat Capacity

Temperature 20ºC
J/gK 0.46
Melting point (ºC) 1400
Max continuous operating temperature in air (ºC) 1200
Magnetic properties non-magnetic



6).Temperature Factors for Electrical Resistivity

20ºC 100ºC 200ºC 300ºC 400ºC 600ºC
1 1.006 1.012 1.018 1.025 1.018
700ºC 800ºC 900ºC 1000ºC 1100ºC 1300ºC
1.01 1.08 1.01 1.014 1.021 -



7)Style of Supply

Alloys name Type Dimension
OhmAlloy109W Wire D=0.03mm~8mm
OhmAlloy109R Ribbon W=0.4~40 T=0.03~2.9mm
OhmAlloy109S Strip W=8~250mm T=0.1~3.0
OhmAlloy109F Foil W=6~120mm T=0.003~0.1
OhmAlloy109B Bar Dia=8~100mm L=50~1000
