0.06mm 0.08mm, 0.1mm NiCr80/20 wire for MF/CF/MOF resistor,bright surface for furnace

0.06mm 0.08mm, 0.1mm NiCr80/20 wire for MF/CF/MOF resistor,bright surface for furnace
0.06mm 0.08mm, 0.1mm NiCr80/20 wire for MF/CF/MOF resistor,bright surface for furnace 0.06mm 0.08mm, 0.1mm NiCr80/20 wire for MF/CF/MOF resistor,bright surface for furnace

Large Image :  0.06mm 0.08mm, 0.1mm NiCr80/20 wire for MF/CF/MOF resistor,bright surface for furnace Get Best Price

Product Details:
Place of Origin: China(Shanghai)
Brand Name: OHMALLOY
Certification: ISO,SGS
Model Number: 1560W05B
Payment & Shipping Terms:
Minimum Order Quantity: 5kg
Price: negotiable
Packaging Details: Plastic packing inside, wooden box outside , choose the suitable packing, Alos it can be customized by the clients' demand.
Payment Terms: T/T, , L/C
Supply Ability: 80000Kg/Week
Detailed Product Description
Resistivity: 1.12μΩ.m Shape: Wire
Surface: Bright Application: Furnaces
Elongation: 35% Enamelled: Available
Tensile Strength: 730
High Light:

nichrome resistance wire

,

nickel chromium resistance wire

Cr15Ni60 Nichrome Resistance Wire Ni60Cr15 SWG 25 0.5mm For Bell Furnaces​



OhmAlloy112
(Common Name:Ni60Cr15,Chromel C, Nikrothal 60, N6, HAI-NiCr 60, Tophet C, Resistohm 60, Cronifer II,Electroloy, Nichrome, Alloy C, Alloy 675,Nikrothal 6, MWS-675, Stablohm 675,NiCrC)



OhmAlloy112 is a nickel-chromium alloy (NiCr alloy) characterized by high resistivity, good oxidation resistance ,good form stability and good ductility and excellent weldability. It is suitable for use at temperatures up to 1150°C.

Typical applications for OhmAlloy112 are used in metal sheathed tubular elements,for example,hot plates,

grills,toaster ovens and storage heaters.The alloys is also used for suspended coils in air heaters in clothes dryers,fan heaters,hand dryers etc.

Normal composition%

C P S Mn Si Cr Ni Al Fe Other
Max
0.08 0.02 0.015 0.60 0.75~1.60 15.0~18.0 55.0~61.0 Max 0.50 Bal. -





Typical Mechanical properties(1.0mm)

Yield strength Tensile Strength Elongation
Mpa Mpa %
370 730 35



Typical Physical properties

Density (g/cm3) 8.2
Electrical resistivity at 20℃(Ωmm2/m) 1.12
Conductivity coefficient at 20℃ (WmK) 13



Coefficient of thermal expansion
Temperature Coefficient of Thermal Expansion x10-6/℃
20 ℃- 1000℃ 17





Specific heat capacity
Temperature 20℃
J/gK 0.46



Melting point (℃) 1390
Max continuous operating temperature in air (℃) 1150
Magnetic properties non-magnetic



What are the applications?

Resistance wires are manufactured from nickel alloys which have specialist properties such as electrical resistance, oxidation resistance, strength and corrosion resistance – all at elevated temperatures.

Resistance wire is thus used primarily in resistance heating elements, hot wire cutting, heat sealing, resistors and springs and fasteners for high technology industries. It is also used extensively as a glass sealing element.



Temperature Factors Of Electrical Resistivity

20℃ 100℃ 200℃ 300℃ 400℃ 500℃ 600℃
1 1.011 1.024 1.038 1.052 1.064 1.069
700℃ 800℃ 900℃ 1000℃ 1100℃ 1200℃ 1300℃
1.073 1.078 1.088 1.095 1.109 - -



Style of supply

Alloys Name Type Dimension
OhmAlloy112W Wire D=0.03mm~8mm
OhmAlloy112R Ribbon W=0.4~40 T=0.03~2.9mm
OhmAlloy112S Strip W=8~250mm T=0.1~3.0
OhmAlloy112F Foil W=6~120mm T=0.003~0.1
OhmAlloy112B Bar Dia=8~100mm L=50~1000

ALLOY 80/20 NICKEL/CHROMIUM, UNS

Strip, Coil, Foil & Wire,




Description

This alloy can be used at operating temperatures up to 1200°C, (2190°F). Its chemical composition gives good oxidation resistance especially under conditions of frequent switching or wide temperature fluctuations.

Applications

Electrical heating elements for industrial devices such as flat irons, water heaters, plastic moulding dies, soldering irons.

Chemistry Typical

Nickel: 80%
Chromium: 20%

Physical Properties

Density: 0.303 lb/in³, 8.31 g/cm³

Electrical Resistivity: ohm-cir-mil/ft (ohm-mm2/mm):
At 68°F (20°C): 650 (1.08)
At 212°F (100°C): 656 (1.09)
At 392°F (200°C): 662 (1.10)
At 572°F (300°C): 668 (1.11)
At 752°F (400°C): 680 (1.13)
At 1290°F (700°C): 686 (1.14)
At 1470°F (800°C): 686 (1.14)
At 1650°F (900°C): 686 (1.14)
At 1830°F (1000°C): 692 (1.15)
At 2010°F (1100°C): 699 (1.16)
At 2190°F (1200°C): 704 (1.17)

Specific Heat: BTU/lb-°F (J/g-°C):
At 68°F (20°C): 0.107 (0.448)

Thermal Conductivity: BTU-in/hr-ft²-°F (W/m•K):
133 (19.2)

Mean Coefficient of Thermal Expansion: µin/in-°F (µm/m-°C):
At 68-212 °F (20-100 °C): 6.94 (12.5)

Melting Temperature: 2550°F (1400°C)

Forms

Coil-Sheet, Strip, Foil
Wire – Profile, Round, Flat, Square

Mechanical Properties at Room Temperature

Properties: Annealed Typical
Ultimate Tensile Strength: 95000 KSI (655 MPa)

Properties: Tempered
Alloy 80/20 can be cold worked to various tempers. Contact Ulbrich Technical Service for additional information

Additional Properties

Corrosion Resistance
Refer to NACE (National Association of Corrosion Engineers) for recommendations.

Finishes
#1–Hot rolled annealed and descaled. It is available in strip, foil and ribbon. It is used for applications where a smooth decorative finish is not required.
#2D–Dull finish produced by cold rolling, annealing and descaling. Used for deep drawn parts and those parts that need to retain lubricants in the forming process.
#2B–Smooth finish produced by cold rolling, annealing and descaling. A light cold rolling pass is added after anneal with polished rolls giving it a brighter finish than 2D.
#BA-Bright annealed cold rolled and bright annealed
#CBA-Course bright annealed cold rolled matte finish and bright anneal
#2-Cold Rolled
#2BA–Smooth finish produced by cold rolling and bright annealing. A light pass using highly polished rolls produces a glossy finish. A 2BA finish may be used for lightly formed applications where a glossy finish is desired in the formed part.
Polished-Various grit finish for specific polish finished requirements
*Not All Finishes are Available for All Alloys – Consult Sales for Applicable Finishes

Wire Finishes
XC-Extra clean. Bright annealed or bright annealed and cold rolled
Grease-Ultra bright finish for decorative applications
Soap-Soap is not removed from tempered wire to act as a lubricant
*Contact Ulbrich Wire for custom finishes

Heat Treatment
Alloy 80/20 is non hardenable by heat treatment.

Welding
For best results refer to: SSINA’s “Welding of Stainless Steels and Other Joining Methods”.

0.06mm 0.08mm, 0.1mm NiCr80/20 wire for MF/CF/MOF resistor,bright surface for furnace 0

0.06mm 0.08mm, 0.1mm NiCr80/20 wire for MF/CF/MOF resistor,bright surface for furnace 1

0.06mm 0.08mm, 0.1mm NiCr80/20 wire for MF/CF/MOF resistor,bright surface for furnace 2
