Chemical Composition: | ENiCrMo-17 | Application: | Welding High Chromium-nickel Based Alloys |
---|---|---|---|
Shape: | Wire | Dimensions: | 1.0mm |
Color: | Silvery White | Standard: | ASTM,ASTM ASME YB HB BJB GB |
High Light: | C-2000 Welding Filler Wire,1.0mm Thermal Spray Wire,Welding Thermal Spray Wire |
C-2000 welding wire ENiCrMo-17 filler wire N06200 spray wire 1.0mm
Name | Hastelloy C2000 | ||
Chemical Compsition Wt.% |
Ni | balance | |
Cr | min.20 | max.22.5 | |
C | min.- | max.0.015 | |
Mn | min.- | max.0.5 | |
Si | min.- | max.0.08 | |
Fe | min.2 | max.6 | |
P | min.- | max.0.02 | |
S | min.- | max.0.02 | |
Mo | min.12.5 | max.14.5 | |
V | min.- | max.0.35 | |
Co | min.- | max.2.5 | |
W | min.2.5 | max.3.5 |
Physical Constants | |||
Density.g/cm³ | 8.5g/cm³ | ||
Melting Range | 1325-1370℃ | ||
Mechanical Constants | Alloy State | ||
Characters | 1. Corrosion resistance including sulfuric acid, hydrochloric acid | 2.crevice corrosion,stress corrosion cracking | 3.hydrofluoric acid,phosphoric acid,organic acid,chloride, alkali metal,pitting corrosion. |
