|Material:||Fe Ni Co Alloy||Condition:||Soft|
|Wire Diameter Range:||0.1mm ~ 9.0mm||Surface:||Bright|
|Density:||8.27 G/cm3||Application:||Sealing Material For Ceramics|
fe ni alloy,
low expansion alloys
Sealing Ceramic Vacuum Switch Fe Ni Co Alloy Ceramic - To - Metal
Ohmalloy-4J33 for Sealing and matching ceramics
OhmAlloy-4J33 (Expansion alloy)
(Common Name: 33НК, 4J33, KV-4, Ni33Co17)
4J33 alloy has a close Linear expansion coefficient with 95% Al2O3 ceramic in the range of -60 to 600 degrees Celsius. it is an Important sealing structural material in the electric vacuum industry; Mainly used for matching and ceramic sealing.
|Electrical resistivity at 20℃(Ωmm2/m)||0.46|
|Thermal conductivity, λ/ W/(m*℃)||17.6|
|Curie point Tc/ ℃||440|
|Elastic Modulus, E/ Gpa||139|
|The heat treatment process|
|Stress relief annealing||Heating to 470~540℃. Keep 1~2h, cooling in the air|
|Annealing||Heating to 750~ 900℃ In the medium vacuum|
|Holding time, h||15min. ~ 1 hour|
|cooling||In the air|
Coefficient of expansion
Style of supply
|OhmAlloy-4J33||Wire||D= 0.1~8 mm|
|OhmAlloy-4J33||Strip||W= 5~250 mm||T= 0.1 mm|
|OhmAlloy-4J33||Foil||W= 10~100 mm||T= 0.01~0.1 mm|
|OhmAlloy-4J33||Bar||Dia= 8~100 mm||L= 50~1000 mm|
