Kanthal D Strip FeCrAl Alloy 0.5mm x 30mm Bright Working For Neutral Grounding Resistors

Certification
Good quality Bimetallic Strip for sales
Good quality Bimetallic Strip for sales
I search for Nichrome plate long time, and successfully bought it from Ohmalloy material. OHMALLOY provide real good service in alloy service and can always help me in finding the correct resistance alloy.

—— Mike Harness

OHMALLOY can provie me only 1kg Kovar alloy wire 1.0mm with short time, that is really amazing. Thanks

—— Janey

Really professional in thermocouple wire and cable, what i want just can get from OHMALLOY

—— Chris

Enamelled Constantan 0.08mm, i never expect to get only 2kg of it. But OHMALLOY supply it to me with good quality. God Jesus! Such a reliable supplier from china

—— Aaron

I'm Online Chat Now

Kanthal D Strip FeCrAl Alloy 0.5mm x 30mm Bright Working For Neutral Grounding Resistors

China Kanthal D Strip FeCrAl Alloy 0.5mm x 30mm Bright Working For Neutral Grounding Resistors supplier

Large Image :  Kanthal D Strip FeCrAl Alloy 0.5mm x 30mm Bright Working For Neutral Grounding Resistors

Product Details:

Place of Origin: China(Shanghai)
Brand Name: OHMALLOY
Certification: ISO,SGS
Model Number: 23505X30BS

Payment & Shipping Terms:

Minimum Order Quantity: 5kg
Price: negotiable
Packaging Details: Plastic packing inside, wooden box outside , choose the suitable packing, Alos it can be customized by the clients' demand.
Payment Terms: T/T, Western Union, L/C
Supply Ability: 80000Kg/Week
Contact Now
Detailed Product Description
Resistivity: 1.35μΩ.m Shape: Strip
Surface: Bright Application: Resistor
Density: 7.25 Elongation: 23min

Kanthal D Strip FeCrAl Alloy 0.5mm x 30mm Bright Working For Neutral Grounding Resistors



OhmAlloy142B
(Common Name:0Cr25Al5,Aluchrom-O)



OhmAlloy142B is a iron-chromium-aluminium alloy (FeCrAl alloy) characterized by high resistance, low coefficient of electric resistance, high operating temperature, good corrosion resistance under high temperature.It is suitable for use at temperatures up to 1250°C.



Typical applications for OhmAlloy142B are used in electric ceramic cooktop,industrial furnace,heaters.





General Information

Resistance wire is a type of high resistance electrical wire. The wire resists the flow of electricity, and converts the electrical energy into heat.



Application for resistance wire includes resistors, heating elements, electric heaters, electric ovens, toasters, and many more.



Nichrome, a non-magnetic alloy of nickel and chromium, is commonly used to make resistance wire because it has a high resistivity and resistance to oxidation at high temperatures. When used as a heating element, resistance wire is usually wound into coils. One difficulty in using nichrome wire is that common electrical solder will not stick to it, so the connections to the electrical power must be made using other methods such as crimp connectors or screw terminals.



FeCrAl, a family of iron-chromium-aluminum alloys (Kanthal APM, A-1, D and AF etc.) used in a wide range of resistance and high-temperature applications is also used in the form of resistance wires.



Normal composition%

C P S Mn Si Cr Ni Al Fe Other
Max
0.06 0.025 0.025 0.70 Max 0.6 20.5~23.5 Max 0.60 4.2~5.3 Bal. -



Typical Mechanical properties(1.0mm)

Yield strength Tensile Strength Elongation
Mpa Mpa %
485 670 23



Kanthal D Strip FeCrAl Alloy 0.5mm x 30mm Bright Working For Neutral Grounding Resistors



FAQ

Q1.Do you attend exhibition every year?



A .Yes



Q2.Is there any discount of the nickel wire?



A. Yes. Bigger quantity will get a discount.



Q3.Information needed if I want a quotation?



A Name, Standard, Material Grade(Chemical Composition), Size Quantity, Weight.



Q4. Can we visit your company/factory before place the order?



A. Yes. Welcome anytime



Q5: How does your factory do regarding quality control?



A. Quality is priority. We always attach great importance to quality controlling from beginning to end.
