Thermocouple Stranded Twisted Tinned Copper Silicone Insulated Wires 3x2.5 Cross Section

Certification
Good quality Bimetallic Strip for sales
Good quality Bimetallic Strip for sales
I search for Nichrome plate long time, and successfully bought it from Ohmalloy material. OHMALLOY provide real good service in alloy service and can always help me in finding the correct resistance alloy.

—— Mike Harness

OHMALLOY can provie me only 1kg Kovar alloy wire 1.0mm with short time, that is really amazing. Thanks

—— Janey

Really professional in thermocouple wire and cable, what i want just can get from OHMALLOY

—— Chris

Enamelled Constantan 0.08mm, i never expect to get only 2kg of it. But OHMALLOY supply it to me with good quality. God Jesus! Such a reliable supplier from china

—— Aaron

I'm Online Chat Now

Thermocouple Stranded Twisted Tinned Copper Silicone Insulated Wires 3x2.5 Cross Section

China Thermocouple Stranded Twisted Tinned Copper Silicone Insulated Wires 3x2.5 Cross Section supplier
Thermocouple Stranded Twisted Tinned Copper Silicone Insulated Wires 3x2.5 Cross Section supplier Thermocouple Stranded Twisted Tinned Copper Silicone Insulated Wires 3x2.5 Cross Section supplier Thermocouple Stranded Twisted Tinned Copper Silicone Insulated Wires 3x2.5 Cross Section supplier

Large Image :  Thermocouple Stranded Twisted Tinned Copper Silicone Insulated Wires 3x2.5 Cross Section

Product Details:

Place of Origin: China(Shanghai)
Brand Name: OHMALLOY
Certification: ISO9001-2008
Model Number: K-HP-HP-817

Payment & Shipping Terms:

Minimum Order Quantity: 2000meters
Price: negotiable
Packaging Details: 100m/spool
Delivery Time: 10 days
Payment Terms: L/C, T/T, Western Union, D/P, D/A
Supply Ability: 500000meters per month
Contact Now
Detailed Product Description
Material: Tinned Copper Insulation: Silicone Rubber
Diameter: 3x2.5m㎡ Color: ANSI Code
Jacket: Silicone Rubber Surface: Bright&Annealed
Type: Ohmalloy K-HP-HP-817

Thermocouple Stranded Twisted tinned Copper silicone insulated wires 3x2.5 cross section



Product description:

Product name Thermocouple cable
Conductor Material tinned cooper
Insulation material silicone rubber
Conductor Dia 0.25mm*51
Standard ANSI MC 96.1
Insulation Color Red/Yellow or black/brown
Shielding /
Jacket Silicone rubber
Packing 100m/roll
Gross weight 8.2KG/roll
Delivery time 7 working days after payment
Payment T/T or L/C at sight, Paypal
Shipping By DHL, Fedex, Aramex, etc.



Rated Voltage 220V
Rated temperature 180°C
Conductor Fit for GB/T3956-1997 requirment
Type 3x2.5m㎡
Conductor material Tinned cooper wire
Stranded Stranded
Stranded cores 51
single wire diameter 0.25mm
Use temperature 180°C
Insulation IEC silicone rubber mixture
Insulation thickness 0.8mm
insulation OD 3.7-3.8mm
ovality less than 15
Jacket thickness 1.0mm
whole cable OD 10.2-11.4mm
Conductor resistance ≦8.21(Ω/Km)




Company profile

Ohmalloy Material Co.,Ltd is a high-tech enterprise which specialized in making all kinds of alloy
such as high resistance alloy, low-resistance copper nickel alloy, FeCrAl alloy and thermocouple
Alloy.
Ohmalloy Material Co.,Ltd have a full production line from melting, surface cleaning, rolling and
slitting, full set of testing machine and can meet all kinds of technical requirement from customer.
Our product is widely used in heating equipment, big steel mill, mineral,electrical equipment, food
machinery,auto industry,aerospace industry.Our product not only is popular in domestic market, but
also been exported to all over the world.
Our company aims to be the best-quality alloy producer in the world.We insist on developing the
more advanced alloy strip technology, to serve all the customer, improve people's living level,make
a more green earth in the future.





Product&Package:

Thermocouple Stranded Twisted Tinned Copper Silicone Insulated Wires 3x2.5 Cross Section

Thermocouple Stranded Twisted Tinned Copper Silicone Insulated Wires 3x2.5 Cross Section
